WATER BASED GLUE LAMINATION MACHINE
Couldn't load pickup availability
Description
APPLICATION
The machine uses white emulsion glue as an adhesive and a high-temperature resistant mesh belt to create a composite layer. Additionally, the mesh belt features automatic deviation correction, ensuring the composite materials are aligned, flat, and free from misalignment.
MAIN PARAMETER
|
MODEL |
RM |
|
MAX PRODUCTION WIDTH: |
2400MM |
|
ROLLER SURFACE WIDTH: |
2600MM |
|
VOLTAGE |
380V 50Hz 3P |
|
HEATING DRUM SIZE |
φ1500*2600 |
|
WORKING SPEED |
20-45 M/MIN |
|
HEATING MODE |
Electric Heating |
|
OVERALL POWER |
About 80kw |
|
COATING METHOD |
Full Coating |
|
DIMENSION |
7000x3000x2650mm |
MAIN FEATURES
· Uses water-based glue, greatly improving product quality and reducing costs.
· Vertical structure with a low breakdown rate and long service life.
· Equipped with a high-quality heat-resistant mesh belt that ensures close contact between laminated materials and the drying cylinder, enhancing the drying effect and improving adhesive strength while keeping the laminated product soft.
· Features two heating systems, allowing users to select one or both to reduce energy consumption and lower costs.
· The surface of the heating roller typically uses Teflon paper, with the option to upgrade to Teflon coating to effectively prevent hot melt adhesive from sticking to the roller and causing carbonization.
· The clamp roller offers both hand wheel and pneumatic control adjustments.
· Includes an automatic infrared cantering control unit that effectively prevents mesh belt deviation, ensuring longer mesh belt life.
· Customized manufacturing options are available.
· Low maintenance cost and easy to maintain.
